Product Details
The Wilcox RAID Xe™ High Power is a compact, advanced aiming and illumination system built for military and law enforcement use in low- and no-light environments. It integrates a visible laser, NIR aiming laser, and a VCSEL NIR illuminator into a single optical bench for streamlined performance and easy zeroing with one windage and elevation adjustment. It features an adjustable IR illuminator for long-range clarity and a 40° wide-angle IR “room” flood for close-quarters use, both delivering clean, speckle-free illumination. Users can select from multiple laser pulse modes and customize controls via compatible Wilcox ERGOCTO remote keypads and grips. Powered by a single CR123 battery, the RAID Xe is designed for flexibility and reliability, with programmable controls and a modular safety cover system—making it a highly capable, all-in-one solution for precise targeting and illumination.
Characteristics
Low Power
| Immersion | 1 meter for 1 hour |
| Boresight Retention | <.5 mrad |
| Laser Type/Wavelength/Power* | Red Visible Laser/640nm/3mW |
| Laser Type/Wavelength/Power* | Infrared Laser/850nm/3.5mW |
| Laser Type/Wavelength/Power* | Infrared Illuminator/840nm/25mW |
High Power
| Immersion | 1 meter for 1 hour |
| Boresight Retention | <.5 mrad |
| Laser Type/Wavelength/Power* | Red Visible Laser/660nm/75mW |
| Laser Type/Wavelength/Power* | Green Visible Laser/520nm/12mW |
| Laser Type/Wavelength/Power* | Infrared Laser/850nm/30mW |
| Laser Type/Wavelength/Power* | Infrared Illuminator/ 840nm/min 50mW – USA 840nm/max 50mW – Europe |
* Nominal Output Power is subject to +/-10% tolerance.
For Laser Safety use Nominal Output Power + 20%.
Features
- One optical bench houses either red or green VIS laser, NIR laser and adjustable NIR VCSEL illuminator
- Adjustable NIR VCSEL illuminator and wide angle fixed NIR VCSEL Room illuminator project precise, speckle-free beams for extreme clarity and optimal combat identification
- Fixed NIR room illuminator provides 40o flood capability
- Optical bench is aligned to the weapon by one windage
and one elevation adjustment - Powered by one (1) CR123 3V battery providing approximately 8 hours of product usage at max settings
- Mounts to any 1913 Picatinny rail secured by 2 shock nuts
- Multi-function keypads provide flexibility in programing custom options
- Five (5) selectable pulse modes on VIS/NIR lasers settings
- On-the-fly laser brightness adjustment
- Security tethered loop tie down
- Remote port accepts Wilcox line of ERGOCTO® Xe Activation Keypads and ERGOCTO Xe Control Grips (optional)
- ERGOCTO Xe Activation Keypads provides three user defined functions regardless of switch position
**User interchangeable modular visor/laser safety cover
